MOTOR
●Type: 360-volt permanent magnet ●AC motor in carbon fiber housing
●Maximum power: 80 horsepower (Alpha); 60 horsepower (standard)
●Maximum torque: 764 ft-lbs
●Transmission: Clutchless single-speed
●Final drive: RK MXU UW-ring Gold 520 chain
BATTERY
●Capacity: 7.2 kWh honeycomb magnesium
●Charger: 3.3 kilowatt, 16 amp
●Charge time: 3.5 hours (120-volt); 2 hours (240-volt)
●Estimated range: 1.3 to 6 hours of riding
CHASSIS
●Frame: Chromoly w/ carbon fiber subframe
●Handlebar: ProTaper Fatbar
●Front suspension travel: Fully adjustable damping KYB closed-cartridge inverted 48mm fork: 11.8 inches
●Rear suspension travel: Linkage-assisted fully adjustable KYB shock; 11.9 inches
●Wheels: Aluminum rim w/ steel spokes and CNC-machined aluminum hub (tube or mousse)
●Tires: 5 options
●Front tire: 90/90 x 21
●Rear tire: 140/80 x 18
●Front brake: 260mm disc w/ Brembo 2-piston caliper
●Rear brake: 220mm disc w/ Brembo single-piston caliper
DIMENSIONS and CAPACITIES
●Wheelbase: 58.3 inches
●Rake: 26.1 degrees
●Seat height: 38.0 inches
●Ground clearance: 13.6 inches
●Weight: 264 pounds
●Color: Red
