EBOX3 Stomp electric pit bike

The Stomp EBOX3 is a high-performance electric pit bike designed for off-road enthusiasts seeking a compact yet powerful ride. Building upon the success of its predecessors, the EBOX3 introduces enhanced geometry, upgraded suspension, and a robust battery system, making it a formidable contender in the electric pit bike market.



🏍️ Design & Frame



At the heart of the EBOX3 lies a V2 double cradle frame, constructed from high-strength steel and powder-coated for durability. The design incorporates a removable subframe and a swing-arm-mounted motor, facilitating easy maintenance and customization. The bike’s geometry has been refined with longer, stiffer USD (upside-down) forks and a slackened head tube angle, providing a “big-bike” feel in a mini package. The inclusion of a dropper footpeg bar and high-rise 6061 T6 handlebars further enhances rider ergonomics and control .



⚙️ Performance & Powertrain



The EBOX3 is equipped with a removable 72V 20Ah lithium battery, utilizing 21700 cells capable of delivering a peak current of 180 amps. This high-capacity battery ensures extended ride times and robust power delivery. While the bike is sold as a roller, requiring the purchaser to source their own motor, controller, and throttle, it is designed to accommodate high-performance setups. For instance, pairing the chassis with an Electro & Co ETM Upgrade Kit can unlock the bike’s full potential, offering customizable top speed and acceleration settings .



🛞 Suspension & Handling



Handling is a standout feature of the EBOX3. The front suspension comprises USD forks, while the rear features a custom-designed DNM MT-AR mono-shock with adjustable preload and rebound damping. This setup ensures excellent shock absorption and stability over varied terrains. The bike rolls on 14-inch front and 12-inch rear wheels, fitted with 2.27″ and 3″ tires respectively, providing ample grip and maneuverability. Hydraulic disc brakes with 180mm rotors on both ends deliver reliable stopping power .



📏 Dimensions & Weight



●Seat Height: 66 cm

●Wheelbase: 945 mm

●Ground Clearance: 275 mm

●Weight: 42.5 kg

●Maximum Load Capacity: 85 kg



These dimensions make the EBOX3 suitable for a wide range of riders, offering a balance between agility and stability.



🔋 Battery & Charging



The included 72V 20Ah lithium battery is not only high-capacity but also removable, allowing for convenient charging and potential battery swaps for extended riding sessions. Charging is facilitated by an AC 100-240V charger with an output of 84V at 6A, achieving a full charge in approximately 4-5 hours .



🎨 Aesthetics & Customization



The EBOX3 features striking Megalith graphics, giving it a distinctive and aggressive look. Its modular design allows riders to customize and upgrade components to suit their preferences and performance requirements.



🚀 Conclusio



The Stomp EBOX3 stands out as a versatile and potent platform for riders seeking to delve into electric motocross. Its robust frame, advanced suspension, and high-capacity battery system provide a solid foundation for customization and performance tuning. Whether you’re a seasoned rider looking for a compact off-road machine or an enthusiast eager to build a personalized electric pit bike, the EBOX3 offers the flexibility and quality to meet those aspirations.
